Wind blade adaptor trailer can transport blades of model 121-156. Windmill blade adapter for sale is suitable for the wind turbine blades length of 59.5-76 meters, and the longest can transport the wind blade of 80 meters. The weight of the windmill blade that can be carried is 13-23.5 tons.

The special windmill rotor blade adapter trailer can lift the blades through hydraulic control and rotate itself 360 degrees during driving, avoiding various obstacles during transportation (mountain slopes, trees, houses, bridges, tunnels, etc.), which can greatly reduce the blades. The total length of the windmill rotor blade adapter trailer body can improve the curve passing performance.

Windmill Rotor Blade Transport Adapter Trailer for Sale

Windmill Rotor Blade Transport Adapter Trailer for Sale

Windmill Rotor Blade Transport Adapter Trailer for Sale

Windmill Rotor Blade Transport Adapter Trailer for Sale

Windmill Rotor Blade Transport Adapter Trailer for Sale

Windmill Blade Transport Adapter Details :

Wind Blade Adaptor Trailer Specification :

Dimension: 16250mm*3700mm*5000mm

Loading capacity: 23.5 Tons

Axle: 3 lines 6 axles

Max rotation angle: 360°

Place of Origin: Shandong, China

Suspension: Mechanical Suspension

Function: Wind Power Blade

Landing Gear: Standard 28Ton

Axle: 13/16 Ton Fuwa/BPW/CIMC

Tire: 12R22.5

King pin: 2"(50mm)or3.5"(90mm) JOST

Brake System: Dual Line
