Hohan E7G 430 Tractor Head

Howo e7g tractor head cab manufactured by the welding line composed by international advanced robots, safety and reliable top-level quality in China. Each safety performance index completely meeting the latest legal requirements of China , comprehensively enhancing the safety.

+86 15066768857

+86 15066768857

sales@jiruitruck.com

sales@jiruitruck.com

Product Description

SINOTRUK Hohan Truck Description :

All the Howo e7g tractor head bodies adopt integral steel-framed structure, hard and firm, allowing high collision resistance and external force resistance.

Automatic painting line consisting of robots ensuring the Hohan truck price body appearance quality, corrosion prevention and weather resistance, increasing the effective more than 2 times compared to the conventional electrophoresis painting and allowing higher salvage value of vehicle.

SINOTRUK Hohan E7G Tractor Head Truck Price | Howo Trucks for Sale

Howo E7G Tractor Head Details :

SINOTRUK Hohan E7G Tractor Head Truck Price | Howo Trucks for Sale

SINOTRUK Hohan Truck Specification :

Driving Type	6×4
Engine	Engine model: WD615.69 Euro II emission standard, 4 stroke injection diesel engine, 6 cylinder in-line with water
Clutch	SINOTRUK’s 430C diaphragm spring clutch, hydraulically operating with air assistance
Transmission	Transmission, model HW19710, 10 forward and 2 reverse Ratio:14.28; 10.62; 7.87; 5.88; 4.38; 3.27; 2.43; 1.80; 1.34; 1.00; 13.91/3.18(R)
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Front Axle	New HF7 series, with drum brake system Steering with double T-cross section beam
Rear Axle	ST16 pressed axle housing, single reduction and differential locks between axles; with drum brake system. Ratio: 4.3
Steering	ZF8118, hydraulic steering with power assistance Ratio: 22.2-26.2:1
Braking System	Front and rear drum brake, four-circuit protection valve Service brake: dual circuit compressed air brake Parking Brake: spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust brake
Wheel & Types	Rims: 8.5-20,10 hole-steel Types: 295/80R22.5, 12R22.5, 315/80R22.5, 12.00R20
Driver’s cab	H16 cab, 1 sleeper,
Electrical System	Operating voltage:24V, negative grounded Starter: 24V, 7.5KW Alternator: 3-phrase, 28V, 1500W Batteries: 2×12V, 165Ah Cigar-lighter, horn, headlamp, fog light, brake lights, indicators and reverse lamp
Dimensions in mm	Wheel base (mm)Front wheel track (mm)Rear wheel track (mm)Front overhang (mm)Rear overhang (mm)Approach angle(°)Departure angle(°)Overall Dimension (mm)3825+13502022/20411830150072516707400×2496×3700Dead weight (kg)Rated loading capacity at fifth wheel (kg)Gross combination weight (kg)Front axle loading capacity (kg)Rear axle loading capacity (kg)110001489045000700021000Maximum driving speed(km/h)Maximum gradeability (%)Minimum ground clearance(mm)Minimum turning radius (m)Fuel consumption(L/100km)90(reference data)3529817.135(reference data)

Package and Shipping

1. Wax: Do a wax spraying method to forestall the truck physique from being corroded bymeans of seawater throughout transportation
2. Shipping: By bulk cargo carrier, RORO ship or flat rack. Reliable logistics offerings from well-known freight suppliers make the transporttechnique secure and timely.
3. We warranty that all merchandise has been strictly inspected and is in suitable circumstancesearlier than shipment.

Our Advantages

-----Competitive price
We have more than ten years of experience in exporting used trucks; through extensive comparisons and feedback from customers, our prices are more competitive than other competitors. Our trucks have a fifty to fifteen percent discount based on age.
-----Rich truck brands
We can provide second-hand tractors and dump trucks of different years and brands such as SINOTRUK Howo, Shandeka, Shaanxi Automobile, Jiefang, Dongfeng, GAC Day and Night, and FAW.
-----Reply quickly
Our team consists of a group of hard-working and enterprising individuals working 24/7 to respond to customer inquiries and questions. Most issues can be resolved within 12 hours.

Other Products

If you are interested in our used trucks, please send an inquiry and leave your contact information or send us an email. We will respond to you within two hours and configure a suitable used truck according to your needs and give you the best price.

Contact Us Now

Truck Parts for Sale

In addition to used tractors and dump trucks, you can buy even more tractor and dump truck accessories here! For example, SINOTRUK, SHACMAN, FAW, FOTON, Dongfeng, Hino, Volvo, etc.

1. No minimum order quantity limit;
2. The best quality supply channels give you the best prices;
3. We have a large inventory of truck accessories of various brands and can deliver them on time;
4. The most professional foreign trade personnel provide you with one-stop service.

FAQ

Q1： What can you buy from us?
A：Used tractor head, used dump truck, semi-trailer, construction truck, electric car, construction machinery, trailer accessories and truck accessories.
Q2： How about quality control of your company?
A： We pay great attention on quality control from the beginning to the end,and our QC department will inspect all vehicle strictly before shipment delivery.Third party inspection is welcome.
Q3： When is your delivery time?
A： Within 20-30 days after ordering.
Q4：Is it all right to make customer brand name?
A： Yes, OEM is welcome if the quantity above the MOQ.
Q5： Where is your loading port?
A： Qingdao, China.
Q6：why should you buy from us not from other suppliers?
A：We have first-class production equipment, strong technical force and advanced testing methods to provide you with more stable and reliable vehicles.
